S10035
废液桶
waste barrel 26 A212403
加热包盖ⅡC
cover IIC of heating box
2 P112108-24
弯头
syphon 27 E05019
温度探头
temperature sensor
ZH001
废液桶-彩显液位探头 waste liquor level sensor(for CD) 28 A212415
补液弯管
replenishing pipe elbow
ZH008
废液桶-漂定液位探头 waste liquor level sensor(for BF) ZH052
水箱药包-漂定液位探头
liquor level sensor(for CD)
ZH004
废液桶-稳定液位探头 waste liquor level sensor(for STB) ZH013
水箱药包-稳定1液位探头
liquor level sensor(for STB 1)
4 ZH108
废液桶盖组件
waste barrel cover ZH053
水箱药包-稳定2液位探头
liquor level sensor(for STB 2)
5 A212302
废液弯头接头
waste elbow joint ZH054
水箱药包-稳定3液位探头
liquor level sensor(for STB 3)
6 A202549
废液桶底板
waste barrel bottom board E07002
不锈钢加热棒(彩显用)
stainless steel heating pole
7 A202430
水箱搁条焊合件
tank supporting board E07012
钛加热棒(漂定用)
titanium heating pole(for BF)
8 S10061
阀体
valve body E07020
钛加热棒(稳定用)
titanium heating pole(for STB )
9 S10080
阀门小O型圈
valve O ring (small) 31 A202505
存水盘
water deposit plate
10 S10076
卷盖
valve cover 32 A212416
暗盒座
dark box holder
11 S10014
手柄
handle 33 S04029
扭簧(暗盒座)
distort spring
12 P112203-04
法兰盖
cover 34 A212417
暗盒座盖
dark box holder cover
13 S10079
阀门大O型圈
valve O ring (big) 35 A212401
水箱盖
tank cover
14 A212202
药液箱上盖
cover of tank 36 A212418
试条暗盒组件
dark box discreteness
P112204-06
胶木球(黑)
wooden rubber ball(black)
P112204-05
胶木球(红)
wooden rubber ball(red)
16 A212204
搅拌棒合件
stirring bar
17 A212201
药液箱焊合件(总成)
tank
18 A212101
水箱
tank
19 E06011
15R循环泵
circulation pump
20 A202471
循环泵底板
circulation pump bottom board
21 S10016
喉箍φ20
Φ20 hoop
22 D202514A
补液泵底板
bottom board of replenishing pump
23 E06003
单头补液泵
single-head replenishing pump
24 A212402
加热包盖ⅡB
cover IIB of heating box
25 P112109
加热盒盖1 coverⅠof heating box
D215001
后支架
back bracket 29 A209213
传动齿轮(16牙)
16 teeth gear
2 GK112-D101 光检
sensor
30
Φ 4开口挡圈
retainer ring
3 A215001
20芯插座架1
bracket of 20 pins socket
31 S04021
拉簧 (0.4*3*63)
extension spring(0.4*3*63)
4 E09145 20芯接插件
20 pins socket
32 S02011
差动滚针轴承
unidirectional needle bearing
5 A215003
导轨板
guide board
33 A215004
过桥用短轴一
short roller 1
6 D207006 32牙介动齿轮
32 teeth gear
34 A215020
过桥用长轴一
long roller 1
7 A209116
介动齿轮轴
gear shaft
35 A207013 21牙介动齿轮
21 teeth gear
8 A208144-01
Φ 6卡片
Φ6 ring 36 D215009
双轧道被动辊
distributor axis(passiveness)
9 A208145
垫圈
washer
37 S04012
拉簧 (0.4*3*90)
extension spring(0.4*3*90)
10 U109127A 20牙扁齿轮
20 teeth gear
38 D215008
双轧道主动辊
distributor axis(initiative)
11
39 LSL-D101
摆道光检发射板 LSL.PCB
12 D215010
21牙铝合金齿轮
21 teeth aluminum gear
40 D215005
上导向板焊合件
up guide board
13 E06009
步进电机(57BYG306) stepping motor(57BYG306)
41 LSE-D102
摆道光检接收板
LSE.PCB
14 D215006A
活动架左旁板
left sideboard of flexible bracket
42 A208125
支撑轴
supporting shaft
15 D215004
导杆2
leader shaft 2 43 D215015
中间导向板(下)
middle guide board (down)
16 D215003
导杆1
leader shaft 1 44 A215011
纸架中间导向
rack middle guide
17 S02008
轴承
beeline bearing
45 D215014
中间导向板(上)
middle guide board (up)
18 A215018
直线轴承座
beeline bearing holder
46 A215010
导向板
guide board
19 S01298
轴用挡圈
retainer ring
47 A215027
光电管支架2
bracket 2 of sensor
20 A215024
拉板焊合件
stretch board
48 A215028
光电管盖板
glass cover of sensor
21 A215025
压板
press board
49 E06008
步进电机(57BYG301)
stepping motor(57BYG301)
22 D215007
活动架右旁板
right sideboard of flexible bracket
50 D215002
双轧道电机安装板
dual-ramp motor fixing board
23 A215021
过桥用短轴二
short roller 2
51 A215013
同步轮(三)(Φ6.4)
11 teeth synchronous wheel 3
24 A215005
过桥用长轴二
long roller 2
52 A215014
11牙同步轮(六)(Φ7) 11 teeth synchronous wheel 6
25 A207018
四氟套1
plastic bearing 1
53 A215023
从动轴
driven shaft
26 A215022
过桥用短轴三
short roller 3
54 S03028
同步带
synchronous belt
27 D215013
双轧道橡胶套
guide rubber blet
28 A208141
轴套
plastic bearing
A208145
垫圈
washer
29 A207005
提升架拉手轴
handle shaft
2 A208126
架子导向
rack guide
30 U208120
拉手板
handle board
3 A207009
保护板
protection board for guide
31 U207013
架子导向
rack guide
4 A207012
过桥架加强板
intensifying board
32 A208132
12牙齿轮
12 teeth gear
5 A207011
过桥架主链轮轴
main sprocket shaft
33 A207003
提升架搁轴
holder shaft
6 A208131
双联介动齿轮
dual driven gear
34 A207002A
提升架后墙板
back wallboard
7 A207001A
提升架前墙板
front wallboard
35 A209123
支撑轴
supporting shaft
8 A209116
导向轮轴
shaft of gear
36 A207019
12/14双联轮介动轴
shaft of dual gear
9 A207014
12牙介动齿轮
12 teeth gear
37 S10092
塑料垫圈
washer
10 A208144-01 φ 6卡片
φ6 ring
38 A207015
介动双联齿链轮
dual spocket
11 S04021
拉簧
stretch spring
39 A207004
提升架罩
cover of raiser rack
12 A208142
四氟套1
plastic bearing 1
13 A208122
被动辊
driven roller
14 A207010A
提升架进纸导向
guide board
15 A208121
上辊
upper roller
16 A208130 21牙厚齿轮
21 teeth thick gear
17 A208141
轴套
plastic bearing 1
18 A207008A
提升架辊子
roller of raiser rack
19 A208123
槽架导向板
plastic guide
20 A208134
21牙齿轮
21 teeth gear
21 A208112
错位辊一
cross roller 1
22 S04012
拉簧
stretch spring
23 A207006
过桥架底部主动辊 bottom driving roller
24 A208115
橡胶套撑轴一
bottom driven roller
25 A207007
提升架PVC辊
PVC roller of raiser rack
26 S02011
差动滚针轴承
unidirectional needle bearing
27 A207013
21牙介动齿轮
21 teeth gear
28 A208143
φ 4卡片
φ4 ring
A208129
彩显架拉手轴
handle shaft of CD rack
27 A208121
上辊
up roller
2 A208128
拉手板
handle board
28 A208120
主动辊
driving roller
3 A208127
搁轴
handle shanft
29 A208135
12/14双联主动齿轮
12/14 dual driving gear
4 A208145
垫圈
washer
30 A208122
被动辊
driven roller
5 A208126
架子导向
rack guide
31 A208132
12牙齿轮
12 teeth gear
6 A208143
φ 4卡片
φ4 ring
32 S04074
拉簧
stretch spring
7 A208131
12/14双联介动齿轮
12/14 dual driven gear
33 A207018
四氟套2
plastic bearing 2
8 A208124 12/14双联齿轮介动轴 dual driven gear shaft
34 S04073
拉簧
stretch spring
9 A208139
上导向卡扣一
buckle 1 of upper guide
35 A208111
喷淋下固定板
bracket of spraying roller
A208401
彩显前旁板(30")
CD front wallboard(30")
A208405
喷淋轴(30")
spraying roller30")
A208101
彩显前旁板(45")
CD front wallboard(45")
A208107
喷淋轴(45")
spraying roller(45")
11 A208125
支撑轴
supporting shaft
37 A208138
上导向
upper guide
A208402
彩显后旁板(30")
CD back wallboard(30")
38 A208136
上导向动轴
moving axle of upper guide
A208102
彩显后旁板(45")
CD back wallboard(45")
39 A208137
上导向定轴
dead axle of upper guide
13 A208134
21牙齿轮
21 teeth gear
14 A208112
错位辊一
cross roller 1
15 A208141
四氟套
plastic bearing
16 A208144-01 φ 6卡片
φ6 ring
17 A208133
双联齿链轮
dual sprocket
18 A208114
大辊
big roller
19 A208130 21牙厚齿轮
21 teeth thick gear
20 A208113
错位辊二
cross roller 2
21 A208118
橡胶套撑轴四
supporting roller 4 of rubber sleeve
22 A208115
橡胶套撑轴一
supporting roller 1 of rubber sleeve
23 A208117A 橡胶套撑轴三
supporting roller 3 of rubber sleeve
24 A208123
槽架导向板
rack guide board
25 X208107
槽架连接板
connecting board of rack
26 A208119
橡胶套
rubber sleeve
A208127
搁轴
handle shanft
27 A208132
12牙齿轮
12 teeth gear
2 A208140
上导向卡扣二
buckle 2 of upper guide
28 S04074
拉簧
stretch spring
3 A208139
上导向卡扣一
buckle 1 of upper guide
29 A207018
四氟套2
plastic bearing 2
4 A208124 12/14双联齿轮介动轴
dual driven gear shaft
30 S04073
拉簧
stretch spring
5 A208131
12/14双联介动齿轮
12/14 dual driven gear
31 A208138
上导向
upper guide
6 A208143
φ 4卡片
φ4 ring
32 A208136
上导向动轴
moving axle of upper guide
A208301
漂/稳定短插架前旁板
BF/STB front wallboard
33 A208137
上导向定轴
dead axle of upper guide
A208201
漂定插架前旁板
BF front wallboard(45")
8 A208125
支撑轴
supporting shaft
A208302
漂/稳定短插架后旁板
BF/STB back wallboard
A208202
漂定插架后旁板
BF back wallboard(45")
10 A208134
21牙齿轮
21 teeth gear
11 A208112
错位辊一
cross roller 1
12 A208141
四氟套
plastic bearing
13 A208144-01 φ 6卡片
φ6 ring
14 A208133
双联齿链轮
dual sprocket
15 A208114
大辊
big roller
16 A208130 21牙厚齿轮
21 teeth thick gear
17 A208113
错位辊二
cross roller 2
18 A208118
橡胶套撑轴四
supporting roller 4 of rubber sleeve
19 A208115
橡胶套撑轴一
supporting roller 1 of rubber sleeve
20 A208117A 橡胶套撑轴三
supporting roller 3 of rubber sleeve
21 A208123
槽架导向板
rack guide board
22 X208107
槽架连接板
connecting board of rack
23 A208119
橡胶套
rubber sleeve
24 A208135
12/14双联主动齿轮
12/14 dual driving gear
25 A208120
主动辊
driving roller
26 A208121
上辊
up roller
A208140
上导向卡扣2
buckle 2 of upper guide
29 A208113
错位辊二
cross roller 2
2 A209124
搁轴
handle shanft
30 A209121
烘干架错位辊二
cross roller 2 of dryer rack
3 A209119
支撑轴2
supporting shaft 2
31 A209107-02 导风板
cover of wind through
4 A209123
支撑轴
supporting shaft
32 A209105
烘干架铝辊3
aluminum roller 3 of dryer rack
5 A208123
槽架导向板
rack guide board
33 A209109
错位辊八
cross roller 8
6 A208124 12/14双联轮介动轴
dual driven gear shaft
34 A209117
烘干7号架下转弯导向 guide board in bottom
7 A208131
12/14双联介动齿轮
12/14 dual driven gear
35 A209102
烘干架后墙板A
back wallboard A of dryer rack
8 A208143
φ4卡片
φ4 ring
36 A209107
风道板碰焊图
board of wind through
9 A207017
轴套
plastic bearing
37 A209113 11牙链轮
11 teeth sprocket
10 A208133
双联齿链轮
dual sprocket
38 A209110
烘干架链条张紧轮轴
sprocket shaft
11 A208145
垫圈
washer
39 S04031
扭力弹簧
twist spring
12 A208134
21牙齿轮
21 teeth gear
40 A209111
张紧板
strain board
13 A208144-01 φ 6卡片
φ6 ring
41 A209114
张紧板固定轴
strain board shaft
14 A208130 21牙厚齿轮
21 teeth thick gear
42 A209112
从动链轮
driven sprocket
15 A209101
烘干架前墙板A
front wallboard A of dryer rack
43 S03003
滚子链条
chain
16 A209118
导向轮轴
gear shaft
17 A207014 12牙介动齿轮
12 teeth driven teeth
18 A209115 17牙齿轮
17 teeth gear
19 A208132
12牙齿轮
12 teeth gear
20 S04021
拉簧
stretch spring
21 A207018
四氟套1
plastic bearing 1
22 A208122
被动辊
driven roller
23 A209103 PU-吸水辊
roller for absorbing water
24 A208114
大辊
big roller
25 A209104
烘干架铝辊1
aluminum roller 1 of dryer rack
26 A209122
烘干架错位辊一
cross roller 1 of dryer rack
27 A208112
错位辊一
cross roller 1
28 A209120
烘干架橡胶辊2
rubber roller 2 of dryer rack
A208126
架子导向
rack guide
29 A209121
烘干架错位辊二
cross roller 2 of dryer rack
2 A208125
支撑轴
supporting shaft
30 A208113
错位辊二
cross roller 2
3 T06172
热缩管
rubber cover
31 A209207
烘干架铝辊2
aluminum roller 2 of dryer rack
4 A209215
烘干架导向轴
shaft of dyrer exit
32 A209107
风道板碰焊图
board of wind through
5 A209124
搁轴
handle shanft
33 A209109
错位辊八
cross roller 8
6 A209206
烘干架齿轮护板
gear cover board
34 U207013
架子导向
rack guide
7 A209216
烘干架主链轮轴焊接图 driving sprocket shaft
35 A209202
烘干架后墙板B
back wallboard B of dryer rack
8 A207015
双联齿链轮
dual sprocket
36 A209208A
18牙齿轮
18 teeth gear
9 A208134 21牙齿轮
21 teeth gear
37 A209113 11牙链轮
11 teeth sprocket
10 A207017
轴套
plastic bearing
38 S03003
滚子链条
chain
11 A208130 21牙厚齿轮
21 teeth thick gear
39 A209114
张紧板固定轴
strain board shaft
12 A208144-01 φ 6卡片
φ6 ring
40 A209111
张紧板
strain board
13 A209116
介动齿轮轴
gear shaft
41 A209123
支撑轴
supporting shaft
14 A207014 12牙介动齿轮
12 teeth driven gear
42 S04031
扭力弹簧
twist spring
15 A209201
烘干架前墙板B
front wallboard B of dryer rack
43 A209112
从动链轮(Z=12)
driven sprocket
16 A209115 17牙齿轮
17 teeth gear
44 A209110
烘干架链条张紧轮轴
sprocket shaft
17 A209203
烘干出口用长轴
long roller of dryer exit
45 A208143
φ4卡片
φ4 ring
18 A209204
烘干架出口刺毛辊
thorn-shape roller of dryer exit
46 A209107-02 导风板
cover of wind through
19 S10071
刺毛套
thorn-shape coil
47 A208145
垫圈
washer
20 S04026
拉簧
stretch spring
48 A209212
介动齿轮(圆)
driven gear
21 A209213
16牙齿轮
16 teeth gear
22 S10092
塑料垫圈
plastic washer
23 A209205
纸架上导向
plastic guide
24 A209214
支撑轴
supporting shaft
25 A208112
错位辊一
cross roller 1
26 A209104
烘干架铝辊1
aluminum roller 1 of dryer rack
27 A209122
烘干架错位辊一
cross roller 1 of dryer rack
28 A209105
烘干架铝辊3
aluminum roller 3 of dryer rack
表25/List 25 见图21/See Fig. 21
4
E10092
温度继电器
temperature relay
2 A211009
探头压板
clamping board of sensor
3 E05022
温度传感器
temperature sensor
4 A211005
烘干箱底板焊合件
base board
5 E09186
护线套
sheath
6 A211002
出风口罩
cover
7 E10010
宝塔瓷
porcelain
8 A211001
烘干器焊合
welded dryer
9 E07007
电热丝(1200W)
heating wire (1200W)
10 A211006
电热丝支撑板
support board
11 A211010
隔热套
insulated sheath
12 S01294
轴用挡圈
block ring
13 A211003
风机固定板二
fan fixing bracket 2
14 A211004
风机固定板一
fan fixing bracket 1
15 E06068
烘干风机
dryer fan
16 A211008
隔离板
insulated board
A210009A
20牙同步轮
20 teeth synchronous wheel
29 S10093
电阻定位套
resistor fixation bush
2 A210007
轴承座
bearing holder
30 A210021
罩盖防护垫
protecting film
3 S02012
608轴承
bearing 608
31 A210002
罩盖
cover
4 A210010
主动轴
initiative shaft
5 E06060
同步电机
motor
6 A210022
15牙同步轮
15 teeth synchronous wheel
7 S03072
同步带
synchronous belt
8 A210011
大链轮(主动)
big sprocket wheel(initiative)
9 A210006-1
链条垫板
chain supporting board
10 A210004
拨杆合件
floating shaft
11 S03010
滚子链条
chain
12 A210006
托板
supporting board
13 A210019
尾轮轴座
shaft holder
14 A210014
盖板碰焊图
cover board
15 SortTwoSensor-D101 光电传感器
sensor
16 A210016
分户小车短轴
short shaft
17 A210003
分户小车杠杆
lever
18 A210020
支柱
supporting pole
19 S04053
拉簧(带盘头)
spring
20
梅花卡片
ring
21 A210018
拉弹簧小轴
small shaft of stretch spring
22 JK112-D101
光检
sensor
23 A210017
杠杆搁轴
handle shaft
24 A210015
光电管支架
sensor bracket
25
电容(电机自带)
capacitor
26
电阻(电机自带)
resistor
27 A210001
分户小车基板碰焊图
basis board
28 E09029
航空插座
socket
A213005
分户器光电管支架
sensor bracket
2 GK112-D101 光检
sensor
3 A213004
光电感应片
sensor sheet
4 A213006
分户器光电管盘
sensor tray of sorter
5 A208145
垫圈
washer
6 A213016
Φ8四氟套
Φ8 sleeve
7 A213012
18牙链轮
18 teeth sprocket wheel
8 A213010
被动轴(分户器)
driven shaft
9 A213011
分户片
sensor leaf
10 A213003
滑槽
slide piece
11 S03009
链条
chain
12 E02063
电容
capacitor
13 E09030
航空插座
socket
14 A213013
11牙同步轮(五)
11 teeth synchronous wheel
15 E06038
低速同步电机
motor
16 A214008
轴套
axile bush
17 A208144-01
Φ 6卡片
φ6 ring
18 A213009
主动轴(分户器)
initiative shaft
19 A210011
大链轮
big sprocket wheel
20 A207017
轴套
axile bush
21 A214011
32牙同步轮
32 teeth synchronous wheel
22 S03021
同步带
synchronous belt
23 A213018
定位板
orientation plate
24 A213001A
分户器焊合件
welding assembly of sorter assembly
25 A213017
分户器垫块
fill block of sorter assembly
26 A213002A
加强板
cover board
A214004A
接片盒加长板
lengthening board
2 A214012
垫圈
washer
3 A214003A
盖
cover
4 A214002B
接片盒
paper receiving box
5 A208143
φ 4卡片
φ4 ring
6 A214007
20牙齿轮
20 teeth gear
7 S02011
差动滚针轴承
unidirectional needle bearing
8 A208114-01 Φ 6卡片
φ6 ring
9 A214013
齿轮(20牙)
20 teeth gear
10 A207017
轴套
plastic bearing
11 A214014
接片盒挡板
stopper board
12 A214001A
接片盒焊合件
main bracket
13 E06038
同步电机
motor
14 A213013
11牙同步轮
11 teeth synchronous wheel
15 A214008
轴套
plastic bearing
16 A213014
32牙同步轮
32 teeth synchronous wheel
17 S03049
同步带
synchronous belt
18 A214005
接片盒被动轴
driven shaft
19 A214009
滚筒体
roller
20 A214010
刺毛套
thorn-shape sleeve
21 A214006
接片盒主轴
driving shaft
A202420
扬声器板固定板支架
bracket 22
光 驱
CD-ROM
3 D202432A
上机箱支架2
up computer box bracket 23 D202521
主板安装铜柱
copper pole
4 D202521
主板安装铜柱
mainboard fixing copper pole 24
主 板
mainboard
5
主 板
mainboard 25 D202425
下机箱焊合件
down computer box
6 D202428A
上机箱右侧挡板
right spacing plate 26 D202427B
下机箱压板
compaction plate
7
硬 盘
hard disk 27 D202433
转换插头安装架
fixing bracket of BNC
8
光 驱
CD-ROM 28 A202420
扬声器板固定板支架
fixing bracket
9 D202424-05
上机箱面板
up computer box panel 29 D202520
机箱短压柱
short compaction pole
10 U302541
开关安装板
switch fixing plate 30 D202519
机箱长压柱
long compaction pole
11 D202419A USB接口安装板
USB fixing plate 31 D202508
集线器压板
hub compaction plate
12 D202424C
上机箱焊合件
up computer box 32
硬 盘
hard disk
13
电 源
computer power supply 33 U302541
开关安装板
switch fixing plate
14 P102202
按钮支撑座
button sustentation
15 D202505
显示屏安装柱
fixing pole
16 D202507
显示屏垫板
supporting plate
17
鼠标
mouse
18 D202516
键盘板安装柱
Keyboard plate fixing pole
19
键盘
Keyboard
20 V202479
键盘附板
Keyboard plate
